Comparison of FRITZ!Box DSL Models

	FRITZ!Box 7690	FRITZ!Box 7682	FRITZ!Box 7632	FRITZ!Box 7630	FRITZ!Box 7590 AX	FRITZ!Box 7530 AX	FRITZ!Box 7510
ADSL/ADSL2+	- / ✔	- / ✔	- / ✔	- / ✔	✔ / ✔	✔ / ✔	✔ / ✔
VDSL/Supervectoring	✔ / ✔	✔ / ✔	✔ / ✔	✔ / ✔	✔ / ✔	✔ / ✔	✔ / ✔
G.fast	-	✔	✔	-	-	-	-
WAN (Gbit/s)	2.5 Gbit/s	2.5 Gbit/s	2.5 Gbit/s	2.5 Gbit/s	1 Gbit/s	-	-
Wi-Fi/Mesh	Wi-Fi 7	Wi-Fi 7	Wi-Fi 7	Wi-Fi 7	Wi-Fi 6	Wi-Fi 6	Wi-Fi 6
Band (GHz)	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	2.4
Max. Wi-Fi	7.1 Gbit/s	6.9 Gbit/s	3.6 Gbit/s	3.6 Gbit/s	3.6 Gbit/s	2400 Mbit/s	600 Mbit/s
MIMO data streams	4 x 4	4 x 4	2 x 2	2 x 2	4 x 4	4 x 4 at 5 GHz 2 x 2 at 2.4 GHz	2 x 2
Phone system	✔	✔	✔	✔	✔	✔	✔
IP-based	✔	✔	✔	✔	✔	✔	✔
HD telephony	✔	✔	✔	✔	✔	✔	✔
DECT base station	✔	✔	✔	✔	✔	✔	✔
Smart home hub	DECT + Zigbee	DECT	DECT	DECT	DECT	DECT	DECT
Media server/NAS	✔	✔	✔	✔	✔	✔	✔
2.5-gigabit LAN port	2	2	1	1	-	-	-
1-gigabit LAN port	2	2	3	3	4	4	1
USB port	1	1	1	1	2	1	1
Phone (analogue)	2	2	1	1	2	1	1

Comparison of FRITZ!Box Fiber Optic Models

	FRITZ!Box 5690 Pro	FRITZ!Box 5690 XGS	FRITZ!Box 5690	FRITZ!Box 5590 Fiber	FRITZ!Box 5530 Fiber
AON / GPON / XGS-PON	✔ / ✔ / -	- / - / ✔	✔ / ✔ / -	✔ / ✔ / ✔	✔ / ✔ / ✔
DSL	✔	-	-	-	-
WAN (Gbit/s)	2.5 Gbit/s	10 Gbit/s	2.5 Gbit/s	2.5 Gbit/s	via LAN 1
Wi-Fi/Mesh	Wi-Fi 7/Tri-band	Wi-Fi 7	Wi-Fi 7	Wi-Fi 6	Wi-Fi 6
Band (GHz)	6 & 5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4
Max. Wi-Fi	18 Gbit/s	7.1 Gbit/s	6.4 Gbit/s	3.6 Gbit/s	3 Gbit/s
MIMO data streams	4 x 4	4 x 4	4 x 4 at 5 GHz 2 x 2 at 2.4 GHz	4 x 4	2 x 2
Phone system	✔	✔	✔	✔	✔
IP-based	✔	✔	✔	✔	✔
HD telephony	✔	✔	✔	✔	✔
DECT base station	✔	✔	✔	✔	✔
Smart home hub	DECT + Zigbee	DECT	DECT	DECT	DECT
Media server/NAS	✔	✔	✔	✔	-
WAN/LAN port	1	1	1	1	-
2.5-gigabit LAN port	-	-	1	-	1
1-gigabit LAN port	4	4	2	4	2
USB port	1	1	1	2	-
Phone (analogue)	1	1	1	2	1

Comparison of FRITZ!Box Cable Models

	FRITZ!Box 6690 Cable	FRITZ!Box 6670 Cable
Cable	✔	✔
DOCSIS	3.1	3.1
WAN (Gbit/s)	-	-
Wi-Fi/Mesh	Wi-Fi 6	Wi-Fi 7
Band (GHz)	5 & 2.4	5 & 2.4
Max. Wi-Fi	6.0 Gbit/s	3.5 Gbit/s
MIMO data streams	4 x 4	2 x 2
Phone system	✔	✔
IP-based	✔	✔
HD telephony	✔	✔
DECT base station	✔	✔
Smart home hub	DECT	DECT + Zigbee
Media server/NAS	✔	✔
WAN/LAN port	-	-
2.5-gigabit LAN port	1	1
1-gigabit LAN port	3	4
USB port	2	1
Phone (analogue)	2	1

Comparison of FRITZ!Box Mobile Network Models

	FRITZ!Box 6860 5G	FRITZ!Box 6850 5G v2	FRITZ!Box 6850 4G	FRITZ!Box 6850 LTE	FRITZ!Box 6825 4G
Mobile network	5G, LTE, UMTS	5G, LTE, UMTS	LTE, UMTS	LTE, UMTS	LTE, UMTS
Indoor / Outdoor / PoE	✔ / ✔ / ✔	✔ / - / -	✔ / - / -	✔ / - / -	✔ / - / -
Wi-Fi/Mesh	Wi-Fi 6	Wi-Fi 5	Wi-Fi 5	Wi-Fi 5	Wi-Fi 6
Band (GHz)	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	2.4
Max. Wi-Fi	3 Gbit/s	1266 Mbit/s	1266 Mbit/s	1266 Mbit/s	600 Mbit/s
MIMO data streams	2 x 2	2 x 2	2 x 2	2 x 2	2 x 2
Phone system	✔	✔	✔	✔	-
Mobile/IP-based	✔ / ✔	✔ / ✔	✔ / ✔	✔ / ✔	-
HD telephony	✔	✔	✔	✔	-
DECT base station	✔	✔	✔	✔	-
Smart home hub	DECT	DECT	DECT	DECT	-
Media server/NAS	-	✔	✔	✔	-
WAN/LAN port	-	-	-	-	-
2.5-gigabit LAN port	-	-	-	-	-
1-gigabit LAN port	1	4	4	4	1
USB port	-	1	1	1	-
Phone (analogue)	-	1	1	1	-

Comparison of FRITZ!Box Modem Models

	FRITZ!Box 4690	FRITZ!Box 4630	FRITZ!Box 4060	FRITZ!Box 4050
WAN	10 Gbit/s	2.5 Gbit/s	2.5 Gbit/s	1.0 Gbit/s
Wi-Fi/Mesh	Wi-Fi 7	Wi-Fi 7	Wi-Fi 6	Wi-Fi 6
Band (GHz)	5 & 2.4	5 & 2.4	2 x 5 & 2.4	5 & 2.4
Max. Wi-Fi	7 Gbit/s	3.6 Gbit/s	6 Gbit/s	3 Gbit/s
MIMO data streams	4 x 4	2 x 2	4 x 4	2 x 2
Phone system	✔	✔	✔	✔
IP-based	✔	✔	✔	✔
HD telephony	✔	✔	✔	✔
DECT base station	✔	✔	✔	✔
Smart home hub	DECT	DECT	DECT	DECT
Media server/NAS	✔	✔	✔	✔
10-gigabit LAN port	1	-	-	-
2.5-gigabit LAN port	3	1	-	-
1-gigabit LAN port	-	2	3	3
USB port	1	1	1	1
Phone (analogue)	2	1	-	1

Comparison of FRITZ! Mesh Wi-Fi Products

	FRITZ!Repeater 6000	FRITZ!Repeater 3000 AX	FRITZ!Repeater 2700	FRITZ!Repeater 2400	FRITZ!Repeater 1700	FRITZ!Repeater 1610 Outdoor	FRITZ!Repeater 1200 AX	FRITZ!Repeater 600	FRITZ!Powerline 1260	FRITZ!Powerline 1240 AX	FRITZ!Powerline 1220	FRITZ!WLAN USB Stick AC 430
Wi-Fi	Wi-Fi 6	Wi-Fi 6	Wi-Fi 7	Wi-Fi 5	Wi-Fi 7	Wi-Fi 6	Wi-Fi 6	Wi-Fi 4	Wi-Fi 5	Wi-Fi 6	-	Wi-Fi 5
Mesh Wi-Fi	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
Band (GHz)	2 x 5 & 1 x 2.4	2 x 5 & 1 x 2.4	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	5 & 2.4	2.4	5 & 2.4	2.4	-	5 & 2.4
Max. Wi-Fi	6 Gbit/s	4.2 Gbit/s	6.5 Gbit/s	2.4 Gbit/s	3.6 Gbit/s	3 Gbit/s	3 Gbit/s	600 Mbit/s	866 / 400 Mbit/s	600 Mbit/s	-	600 Mbit/s
MIMO data streams	4 x 4 + 4 x 4 + 4 x 4	4 x 4 + 2 x 2 + 2 x 2	4 x 4 + 2 x 2	4 x 4 + 4 x 4	2 x 2 + 2 x 2	2 x 2 + 2 x 2	2 x 2 + 2 x 2	4 x 4	2 x 2	2 x 2	-	1 x 1
Max. channel width	80 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	80 MHz	80 MHz	40 MHz	-	80 MHz
WPA2/WPA3 transition Mode	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
WPS	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
2.5-gigabit LAN port	1	-	1	-	-	-	-	-	-	-	-	-
Gigabit LAN port	1	2	-	1	1	1	1	-	1	2	2	-
Power over Ethernet (PoE+)	-	-	-	-	-	✔	-	-	-	-	-	-
Powerline max. Mbit/s	-	-	-	-	-	-	-	-	1200	1200	1200	-
Smart plug	-	-	-	-	-	-	-	-	-	-	✔	-
IP54-certified housing (protected outdoor areas)	-	-	-	-	-	✔	-	-	-	-	-	-
Set/single product	- / ✔	- / ✔	- / ✔	- / ✔	- / ✔	- / ✔	- / ✔	- / ✔	✔ / ✔	✔ / ✔	✔ / ✔	- / ✔
Available as Mesh Set	-	FRITZ!Mesh Set 4200	-	-	FRITZ!Mesh Set 1700	-	FRITZ!Mesh Set 1600	-	-	-	-	-

Comparison of FRITZ!Mesh Wi-Fi Sets

	FRITZ!Mesh Wi-Fi Set 4200 3-pack	FRITZ!Mesh Wi-Fi Set 4200 2-pack	FRITZ!Mesh Wi-Fi Set 2700 3-pack	FRITZ!Mesh Wi-Fi Set 2700 2-pack	FRITZ!Mesh Wi-Fi Set 1700 3-pack	FRITZ!Mesh Wi-Fi Set 1700 2-pack	FRITZ!Mesh Wi-Fi Set 1600 3-pack	FRITZ!Mesh Wi-Fi Set 1600 2-pack
Wi-Fi	Wi-Fi 6	Wi-Fi 6	Wi-Fi 7	Wi-Fi 7	Wi-Fi 7	Wi-Fi 7	Wi-Fi 6	Wi-Fi 6
Mesh Wi-Fi	✔	✔	✔	✔	✔	✔	✔	✔
Mesh Master	✔	✔	✔	✔	✔	✔	✔	✔
Band (GHz)	1 x 2.4 and 2 x 5	1 x 2.4 and 2 x 5	2.4 and 5	2.4 and 5	2.4 and 5	2.4 and 5	2.4 and 5	2.4 and 5
Max. Wi-Fi	4.2 Gbit/s	4.2 Gbit/s	6.5 Gbit/s	6.5 Gbit/s	3.6 Gbit/s	3.6Gbit/s	3.0 Gbit/s	3.0 Gbit/s
MIMO data streams	4 x 4 + 2 x 2 + 2 x 2	4 x 4 + 2 x 2 + 2 x 2	4 x 4 + 2 x 2 + 2 x 2	4 x 4 + 2 x 2 + 2 x 2	2 x 2 + 2 x 2	2 x 2 + 2 x 2	2 x 2 + 2 x 2	2 x 2 + 2 x 2
Max. channel width	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz
WPA3/WPA2	✔	✔	✔	✔	✔	✔	✔	✔
WPS	✔	✔	✔	✔	✔	✔	✔	✔
Gigabit LAN port	6 (2 per repeater)	4 (2 per repeater)	-	-	3 (1 per repeater)	2 (1 per repeater)	3 (1 per repeater)	2 (1 per repeater)
2.5-gigabit LAN port	-	-	3 (1 per repeater)	2 (1 per repeater)	-	-	-	-

Comparison of FRITZ! Smart Home Products

	FRITZ!Smart Control 440	FRITZ!Smart Control 350	FRITZ!Smart Thermo 302	FRITZ!Smart Energy 250	FRITZ!Smart Energy 210	FRITZ!Smart Energy 200	FRITZ!Smart Gateway	FRITZ!Repeater 100
Gateway (Zigbee 3.0/DECT ULE)	-	-	-	-	-	-	✔	-
Matter bridge	-	-	-	-	-	-	✔	-
For digital electricity meters	-	-	-	✔	-	-	-	-
Door/window sensor	-	✔	-	-	-	-	-	-
Smart plug	-	-	-	-	✔	✔	-	✔
Switch	✔	-	-	-	-	-	-	-
DECT repeater	-	-	-	-	-	-	-	✔
E-paper display	✔	-	✔	-	-	-	-	-
Radiator control	-	-	✔	-	-	-	-	-
Splash-protection (IP44)	-	-	-	-	✔	-	-	-
Measures power	-	-	-	-	✔	✔	-	-
Measures temperature	✔	-	✔	-	✔	✔	-	✔
Measures humidity	✔	-	-	-	-	-	-	-
Reads data from digital electricity meter	-	-	-	✔	-	-	-	-
Switching/control at home and on the go	-	-	✔	-	✔	✔	-	-
Encryption	✔	✔	✔	✔	✔	✔	✔	✔
Automatic updates	✔	✔	✔	✔	✔	✔	✔	✔

Comparison of FRITZ! Phones

	FRITZ!Fon X6/X6 Black	FRITZ!Fon C6/C6 Black	FRITZ!Fon M3
DECT	✔	✔	✔
HD telephony	✔	✔	✔
Answering machine	✔	✔	✔
MWI	✔	✔	✔
Email & RSS	✔	✔	✔
Internet radio	✔	✔	✔
UPnP media player	✔	✔	✔
Colour display	2.4-inch	2.2-inch	-
Keyboard illumination	✔	✔	✔
Volume keys	✔	✔	-
Brightness/motion sensor	✔	✔	-
Headset port	✔	✔	-
Key for quick access	✔	-	-
